Product Details:
|
| Type: | ElectronicField Production Converter, Datavideo CCU | Use: | ElectronicField Production |
|---|---|---|---|
| No. Of Fiber: | 1. |
|
Wavelength |
1310nm / 1550nm / CWDM |
|
Output Power |
-6~-1dBm |
|
Rx sensitivity |
<-18dBm |
|
Transmission Distance |
SM fiber 10+km , MM fiber 300m |
|
Optical connector |
Dul LC /FC/ST/SC/MX/ Lemo / Neutrik (optional) |
SDI input/output:
|
Signal format |
SMPTE 424M, SMPTE 292M, SMPTE 259M |
|
Data rate |
270Mbit/s - 1.48Gbit/s - 3Gbit/s |
|
Cable Equalization |
Automatic cable EQ (Belden 1694A cable) 250m @ 270Mbit/s, 140m @ 1.5Gbit/s, 80m @ 3Gbit/s |
|
SDI interface |
BNC 75 Ohm |
Intercom:
|
Camera Optic Adaptor |
|
|
Interface |
4pin XLR(Male) /5pin XLR(Female)/ 3.5mm headset jack |
|
Microphone |
Mic inputs with mute and pre-amps |
|
Headphone |
with volume up or down |
|
Optic Base Station |
|
|
Interface |
Input:3pin XLR Female , Output: 3pin XLR Male or 5pin XLR or 3.5mm headset jack |
|
Audio |
Balance or unbalance line level |
Tally:
|
Camera Optic Adaptor |
|
|
Interface |
4pin air head or 3pin mini XLR |
|
Output |
Dry Contact Closure or wet +12V |
|
On: short or +12V Off: open or 0V |
|
|
Optic Base Station |
|
|
Interface |
DB9(Male) |
|
Input |
Dry Contact Closure or wet |
|
On: short to GND or TTL low Off: open or TTL high |
|
Remote:
|
Camera Optic Adaptor |
|
|
Interface |
8pin air head or 8pin sony’s remote interface |
|
Data |
RS422 /RS232/RS485 |
|
Optic Base Station |
|
|
Interface |
DB9(Male) or 8pin sony’s remote interface |
|
Data |
RS422 /RS232/RS485 |
|
RJ45 |
